Оптический линейный терминал EPON OLT FD1208S-R1

Наименование

FD1208S-R1

Шасси

Rack

Uplink порты

QTY

12

Copper

10/100/1000M auto-negotiable,RJ45:4pcs

Optical interface

4 GE

10Gb uplink interface

4*10Gb

PON Port

QTY

8

Physical Interface

SFP Slots

Connector Type

1000BASE-PX20+

Max splitting ratio

1:64

USB Port

QTY

1

Connector Type

Type-C

Интерфейс управления

1*100BASE－ TX outband port; 1 CONSOLE port

PON Port Specification（Apply to C-Data PON module）

Transmission Distance

20KM

PON port speed

Symmetrical 1.25Gbps

Wavelength

1490nm TX,1310nm RX

Connector

SC/PC

Fiber Type

9/125μm SMF

TX Power

+2.5～+7dBm

Rx Sensitivity

-27dBm

Saturation Optical Power

-6dBm

10Gb SFP+ Port Specification （Apply to C-Data 10Gb module）

Transmission Distance

10KM

PON port speed

8.5-10.51875Gbps

Wavelength

1310nmTX， 1310nmRX

Connector

LC

Fiber Type

Single mode with dual fiber

TX Power

-8.2~+0.5 dBm

Rx Sensitivity

-12.6dBm

Управление

SNMP, Telnet, CLI management mode.

Функции управления и мониторинга

Fan Group Detecting
Port Status monitoring and configuration management;
Layer-2 switch configuration such as Vlan, Trunk ,RSTP,IGMP ,QOS, etc;
EPON management function: DBA ,ONU authorization, ACL ,QOS ,etc;
Online ONU configuration and management
User management
Alarm management

L2 Функции коммутатора

Support port VLan and protocol Vlan
Support Vlan tag/Untag ,vlan transparent transmission;
Support 4096 VLAN
Support 802.3dd trunk
RSTP
QOS based on port ,VID,TOS and MAC address
IGMP Snooping
802.x flow control
Port stability statistic and monitoring

EPON Функции

Support port-based rate limitation and bandwidth control;
In compliant with IEEE802.3ah Standard
Up to 20KM transmission Distance
Support data encryption, group broadcasting, port Vlan separation,
RSTP, etc.
Support Dynamic Bandwidth Allocation (DBA)
Support ONU auto-discovery/Link detection/remote upgrade of
software;
Support VLAN division and user separation to avoid broadcast storm;
Support various LLID configuration and single LLID
configuration .Different user and different service could provide
different QoS by means of different LLID channels.
Support power-off alarm function ,easy for link problem detection
Support broadcasting storm resistance function
Support port isolation between different ports
Support ACL and SNMP to configure data packet filter flexibly
Specialized design for system breakdown prevention to maintain stable
system
Support dynamic distance calculation on EMS online
Support RSTP,IGMP Proxy

L3 Функции

Support static unicast
Support static multicast
Support RIP routing protocol
Support dynamic multicast protocol with active source

Производительность Backplane Bandwidth

116G

Размеры

440*296*44(mm*mm*mm）

Вес

4.50kg

Параметры питания

220VAC

AC: 100V～240V， 47/63Hz

-48DC

DC:-36V～-72V

Потребляемая мощность

58W

Условия окружающей среды

Рабочая температура

0～50℃

Температура хранения

-40～85℃

Влажность

5～90%(non-condensing)
