Оптический линейный терминал EPON OLT FD1104SN-R1

Item

FD1608SN-R1

Uplink Port

Copper

QTY

10/100/1000M auto-negotiable,RJ45:4pcs

8

SFP

4 SFP slots

PON Port

Physical Interface

SFP Slots

QTY

4

Connector Type

1000BASE-PX20+

Max splitting ratio

1:64

Management Port

1*10/100/1000Mauto-negotiable outband port

1CONSOLE port

USB Port

1 Type-C interface

Similar to the CONSOLE port function, used for serial port login

PON Port Specification（ Apply to C-Data PON module）

Wavelength

1490nm TX,1310nm RX

Connector

SC/PC

Fiber Type

9/125μm SMF

TX Power

+2.5～+7dBm

Rx Sensitivity

-27dBm

Transmission Distance

20KM

PON port speed

Symmetrical 1.25Gbps

Saturation Optical
Power

-6dBm

Management Mode.

SNMP, Telnet, CLI management mode

Management Function

Fan Group Detecting
Port Status monitoring and configuration management;Layer-2 switch configuration such as Vlan, Trunk ,RSTP,IGMP ,QOS, etc;
EPON management function: DBA ,ONU authorization, ACL ,QOS ,etc;
Online ONU configuration and management
User management
Alarm management

Layer-two Switch

Support port VLan and protocol Vlan
Support Vlan tag/Untag ,vlan transparent transmission;
Support 4096 VLAN
Support 802.3dd trunk
Support RSTP
Support QOS based on port ,VID,TOS and MAC address
Support IGMP Snooping
Support 802.x flow control
Support Port stability statistic and monitoring

EPON Function

Support port-based rate limitation and bandwidth control;
In compliant with IEEE802.3ah Standard
Up to 20KM transmission Distance
Support data encryption, group broadcasting, port Vlan separation,
RSTP, etc.
Support Dynamic Bandwidth Allocation (DBA)
Support ONU auto-discovery/Link detection/remote upgrade of
software;
Support VLAN division and user separation to avoid broadcast storm;
Support various LLID configuration and single LLID
configuration .Different user and different service could provide
different QoS by means of different LLID channels.
Support power-off alarm function ,easy for link problem detection
Support broadcasting storm resistance function
Support port isolation between different ports
Support ACL and SNMP to configure data packet filter flexibly
Specialized design for system breakdown prevention to maintain stable
system
Support dynamic distance calculation on EMS online
Support RSTP,IGMP Proxy

Backplane Bandwidth

18G

Dimension

440*230mm*44mm(L*W*H)

Weight

3.4kg(without package)

Power Supply

220VAC： AC: 90V～240V， 47/63Hz

Power Consumption

34W

Operating Environment

Working temperature

0～50℃

Storage temperature

-40～85℃

Relative humidity

5～90% (Non-condensing)
